MISSION EXPART Urine Analyzer (U120 Smart)
The Mission® Expert U120 Smart Urine Analyzer is a compact, high-performance urinalysis system designed for fast, accurate, and reliable testing. Using advanced reflectance photometry, it delivers up to 120 tests per hour, stores the last 2,000 results, and features a built-in thermal printer, multi-language interface, and flexible connectivity via USB and RS232C ports — making it the ideal solution for clinics, laboratories, and hospitals.
0
People watching this product now!
Description
Mission® Expert U120 Smart Urine Analyzer – Smart, Fast & Reliable Urinalysis
The Mission® Expert U120 Smart Urine Analyzer combines cutting-edge reflectance photometry technology with smart connectivity features to deliver precise and consistent urinalysis results. Designed for both small clinics and busy laboratories, the U120 offers an excellent balance of speed, accuracy, and ease of use.
With a throughput of up to 120 tests per hour in continuous mode and a strip incubation time of just 1 minute, the U120 enables efficient workflow and rapid diagnostics. Its dual-wavelength detection (525 nm and 635 nm) using a photosensitive diode ensures highly accurate readings across a wide range of urine parameters.
Key Features
- Methodology: Reflectance Photometry
- Detection: Photosensitive Diode
- Throughput:
- Single Test Mode: 60 tests/hour
- Continuous Test Mode: 120 tests/hour
- Memory: Stores the last 2,000 results
- Incubation Time: 1 minute
- Detection Wavelengths: 525 nm and 635 nm
- Built-in Thermal Printer (included)
- Optional External Printer Support
- Barcode Reader Support (RS232C – optional)
- Data Transfer: USB or RS232C cable (optional)
- Multi-Language Display: English default; multiple languages supported
- Barcode Compatibility: Code 128, Code 39, Codabar (NW-7), EAN8, EAN13, Interleave 25, UPCA, UPCE
Technical Specifications
| Specification | Detail |
|---|---|
| Operating Conditions (Analyzer) | 0–40°C (32–104°F); ≤85% RH (non-condensing) |
| Operating Conditions (Strip) | 15–30°C (59–86°F); ≤85% RH (non-condensing) |
| Power Source | 100–240V AC, 50/60Hz, 35 VA |
| Weight | 1.85 kg (4.1 lbs) |
| Dimensions (L x W x H) | 27.5 cm x 18.3 cm x 13.9 cm (10.8″ x 7.2″ x 5.5″) |
| Display Dimensions | 10.8 cm x 6.5 cm (4.2″ x 2.6″) |
| Certification | CE marked for sale in the European Community |
