YANKER Patient Monitor (Touch) PM-LP1A
Technical Specifications at a Glance
| Category | Details |
| Model | PM-LP15A |
| Display | 15″ TFT, 1024×768 resolution |
| ECG Leads | 5-lead (RA, LA, LL, RL, V) |
| Heart Rate Range | 15–380 bpm |
| Respiration Range | Adult: 0–120 bpm; Pediatric/Neonate: 0–150 bpm |
| SpO2 Range | 0–100% (±2% accuracy 70–100%) |
| NIBP Range (Adult) | SYS: 40–270 mmHg; DIA: 10–215 mmHg; MEAN: 20–235 mmHg |
| Temperature Range | 0–50°C (±0.1°C accuracy) |
| IBP (Optional) | ART, PA, CVP, RAP, LAP, ICP, P1, P2 |
| CO2 (Optional) | Mainstream/Sidestream, 0–150 mmHg |
| Battery | 5200mAh Li-ion, 4+ hours runtime |
| Weight | 4.5 kg (approx.) |
| Connectivity | Wi-Fi, VGA, HDMI, USB, Central Station integration |
| Standards | CE, ISO13485, Class I, BF/CF rated |
Optional Modules & Accessories
| Module | Description |
| EtCO2 | Mainstream or sidestream capnography |
| IBP | Invasive blood pressure (up to 2 channels) |
| Multi-Gas (AG) | CO₂, N₂O, SEV, ISO, ENF, HAL, DES |
| BIS | Bispectral index for anesthesia depth |
| Cardiac Output | Thermodilution method |
| Nellcor SpO2 | Enhanced motion-tolerant SpO2 |
| Thermal Recorder | Internal dot array printer, 3 traces |
| Touch Screen | Intuitive touch interface |
| Trolley / Hanging Bracket | Mounting solutions |
Ideal Applications
- Intensive Care Units (ICU / CCU)
- Operating Rooms (OR)
- Emergency Departments (ED)
- Post-Anesthesia Care Units (PACU)
- Neonatal Intensive Care Units (NICU)
- General Medical-Surgical Wards
- Pre-Hospital & Intra-Hospital Transport
Why Choose the PM-LP15A?
The PM-LP15A is engineered for healthcare providers who demand clinical excellence, modular flexibility, and intelligent connectivity. Its large 15-inch display ensures clear visibility of critical patient data, while advanced ECG algorithms deliver reliable ST segment analysis and arrhythmia detection. With wireless central monitoring integration, clinicians can access patient information from anywhere in the facility, enabling faster response times and more coordinated care.
The monitor’s dual-slot modular design allows for easy parameter expansion, making it a future-proof investment for facilities with evolving clinical needs. The no-fan design ensures quiet operation and reduced maintenance, while the 5200mAh battery provides over 4 hours of runtime for uninterrupted monitoring during transport or power outages.
Backed by international certifications and a robust safety profile, the PM-LP15A delivers exceptional value for facilities seeking a comprehensive, reliable, and scalable monitoring solution.
Contact us today to learn more about the PM-LP15A Multi-Parameter Patient Monitor or to request a quote.
0
People watching this product now!
Description
Comprehensive, Reliable, and Intelligent Patient Monitoring
The PM-LP15A Multi-Parameter Patient Monitor is a high-performance, feature-rich monitoring solution designed to meet the rigorous demands of modern healthcare environments. Featuring a 15-inch high-resolution color TFT display with 1024×768 resolution, the PM-LP15A delivers exceptional clarity for real-time visualization of patient waveforms and vital signs. With support for adult, pediatric, and neonatal patients, this monitor is ideal for ICUs, CCUs, operating rooms, surgical wards, emergency departments, and pre-hospital transport.
Backed by CE, ISO13485, and SFDA Class IIb certifications, the PM-LP15A combines clinical accuracy, advanced parameter options, and wireless connectivity to deliver a comprehensive monitoring solution that enhances patient care and workflow efficiency.
Key Features
Large, High-Resolution Display
- 15-inch real color TFT screen with 1024×768 resolution provides crisp, detailed visualization of patient data.
- Multiple display modes: Large font, full/half-screen seven-channel, ST segment analysis, and QRS analysis views.
- Three alarm indicators (yellow/red) with visual and audible alerts for critical events.
Comprehensive Standard Parameters
- ECG (5-lead: RA, LA, LL, RL, V) with diagnostic, monitoring, and surgery bandwidth modes
- Respiration (RESP) – Impedance method (RA-LL)
- SpO2 with pulse rate monitoring
- NIBP – Manual, Auto, and STAT modes
- Dual Temperature (2-TEMP) – Two-channel temperature monitoring
- Pulse Rate (20–300 bpm)
Optional Advanced Parameters
Expand monitoring capabilities with modular options:
- Invasive Blood Pressure (IBP) – Multiple pressure labels (ART, PA, CVP, RAP, LAP, ICP, P1, P2)
- EtCO2 – Mainstream or sidestream capnography
- Multi-Gas (AG) Module – CO₂, N₂O, and anesthetic agents (SEV, ISO, ENF, HAL, DES)
- BIS Module – Bispectral index for depth of anesthesia monitoring
- Cardiac Output (C.O.) Module
- Nellcor SpO2 for enhanced motion tolerance
- Touch Screen for intuitive navigation
- Internal Thermal Recorder for on-demand documentation
Smart IT Integration & Wireless Connectivity
- Wi-Fi connectivity enables seamless integration with a Central Monitoring Station
- Central Monitor System supports:
- Up to 8 waveforms per monitor
- 16 monitors displayed on a single screen
- 64 beds viewable in real-time on one platform
- 240 hours of dynamic trend data for comprehensive patient review
- Wireless patient data management allows remote monitoring from anywhere in the facility
Extensive Data Management
- Trend Diagram/Table: 7 days × 24 hours of continuous data
- NIBP Review: 400 events
- Waveform Review: 100 minutes
- Alarm Review: 100 alarm events
- Drug Concentration Titration Analysis: Supports clinical decision-making
Advanced ECG Capabilities
- ST Segment Detection: Range from -2.0mV to +2.0mV with ±0.02mV accuracy
- Multi-Lead Analysis: I, II, III, aVR, aVL, aVF, V
- Multiple Bandwidth Modes:
- Diagnostic Mode: 0.05–130 Hz
- Monitoring Mode: 0.5–40 Hz
- Surgery Mode: 1–20 Hz
- Defibrillation Protection: Baseline recovery within ≤3 seconds after defibrillation
- CMRR: ≥100 dB for superior noise rejection
High-Performance SpO2 & NIBP
- SpO2 Accuracy: ±2% (70–100% range)
- NIBP: Pulse wave oscillometry with adult, pediatric, and neonatal ranges
- Overvoltage Protection: Prevents patient injury (Adult: 300 mmHg, Pediatric: 240 mmHg, Neonatal: 150 mmHg)
Extended Battery Life & Quiet Operation
- 5200mAh lithium battery: Provides over 4 hours of continuous operation after full charge
- 5-minute operating time after low battery alarm
- No-fan design: Eliminates dust accumulation, reduces noise, and prevents secondary contamination
Enhanced Safety & Durability
- Anti-electroshock Class I equipment (internal power supply)
- CF rated for ECG/Respiration – highest level of cardiac protection
- BF rated for TEMP/SpO2/NIBP
- Anti-defibrillation and anti-high-frequency knife protection
- Supports VGA and HDMI expansion for external display connectivity
Flexible Mounting & Transport Options
- Trolley bracket and hanging bracket options for bedside or transport use
- Dual-slot modular design for easy parameter expansion
- USB storage support for convenient data export
