TRIUP Vertical Pressure Steam Sterilizer TRS-H50L
Technical Specifications
| Specification | Details |
| Model | TRS-H50L |
| Type | Horizontal Steam Sterilizer |
| Volume | 50 L |
| Chamber Size | Φ320 × 655 mm |
| Chamber Material | SUS304 Stainless Steel |
| Working Temperature Range | 115–129°C |
| Working Pressure Range | 0.145–0.165 MPa |
| Sterilization Time Range | 0–80 minutes |
| Power Supply | AC 220V, 50Hz, 2.5 KW |
| Packing Dimensions | 56 × 56 × 105 cm |
| Gross Weight / Net Weight | 60 kg / 40 kg |
| Pressure Gauge | Dual-scale indicator |
| Status Indicators | Light indicators for working status |
| Safety Features | Water lack protection, over pressure discharge, over current protection, over temperature protection |
Ideal Applications
- Dental Clinics & Oral Surgery
- Small Medical Clinics
- Veterinary Practices
- Medical & Research Laboratories
- Beauty & Tattoo Studios
- Podiatry & Chiropractic Offices
- Ambulatory Surgical Centers
Why Choose the TRS-H50L?
The TRS-H50L Horizontal Steam Sterilizer combines durable SUS304 stainless steel construction with intuitive controls and comprehensive safety features to deliver reliable sterilization performance in a compact, space-saving package. The adjustable sterilization temperature and time allow operators to customize cycles for different load types, from surgical instruments to glassware and laboratory equipment.
Safety is paramount in any sterilization environment. The TRS-H50L’s multiple protection systems—including water lack protection, over pressure discharge, and over temperature protection—provide peace of mind for operators and protect both personnel and valuable instruments.
With its 50-liter capacity, compact footprint, and lightweight design, this sterilizer is ideally suited for smaller clinical settings that require dependable, high-quality sterilization without occupying excessive floor space.
0
People watching this product now!
Description
Reliable, Compact Steam Sterilization for Small to Medium Workloads
The TRS-H50L Horizontal Steam Sterilizer is a compact, high-performance autoclave designed for efficient and reliable sterilization in clinics, dental offices, laboratories, and small medical facilities. Featuring a 50-liter stainless steel chamber constructed from high-quality SUS304 stainless steel, this sterilizer delivers consistent performance with an intuitive interface that allows operators to set sterilization temperature and time according to specific load requirements.
Equipped with comprehensive safety protections—including water lack auto-protection, over pressure auto-discharging, over current auto-protection, and over temperature auto-protection—the TRS-H50L ensures safe operation while protecting both personnel and instruments. A dual-scale pressure gauge and light indicators provide clear, at-a-glance status updates throughout the sterilization cycle.
Key Features
High-Quality SUS304 Stainless Steel Construction
The sterilization chamber is constructed from SUS304 stainless steel, a premium material known for its excellent corrosion resistance, durability, and ease of cleaning. This ensures long-term reliable performance even in demanding clinical environments.
Dual-Scale Pressure Gauge
The dual-scale pressure gauge provides clear visualization of chamber pressure in multiple units, allowing operators to monitor sterilization conditions at a glance.
Light Indicators for Working Status
Intuitive light indicators clearly display the sterilizer’s working status, making it easy to determine when cycles are in progress, complete, or if attention is required.
Adjustable Sterilization Temperature and Time
Operators can set sterilization temperature and sterilization time to match the specific requirements of different loads:
- Temperature range: 115–129°C
- Time range: 0–80 minutes
Comprehensive Safety Protection
The TRS-H50L incorporates multiple safety features to ensure reliable and safe operation:
- Water Lack Auto-Protection: Automatically interrupts operation when water levels are insufficient, preventing damage and ensuring cycle integrity.
- Over Pressure Auto-Discharging: Automatically releases excess pressure when safe limits are exceeded.
- Over Current Auto-Protection: Protects electrical components from damage due to power surges.
- Over Temperature Auto-Protection: Prevents unsafe temperature conditions by automatically interrupting operation.
