TRIUP Vertical Pressure Steam Sterilizer TRS-100L (Auto)
Technical Specifications
| Specification | Details |
| Model | TRS-100L(AUTO) |
| Type | Automatic Horizontal Steam Sterilizer |
| Sterilizing Chamber Volume | 100 L (φ440 × 650 mm) |
| Chamber Material | Fully Stainless Steel |
| Working Pressure | 0.22 MPa |
| Maximum Working Pressure | 0.23 MPa |
| Working Temperature | 134°C |
| Temperature Adjustment Range | 105–134°C |
| Heat Average | ≤ ±1°C |
| Timer Range | 0–99 min or 0–99-hour 59 min |
| Power Supply | AC 220V, 50Hz, 4.5 KW |
| Overall Dimensions | 540 × 560 × 1250 mm |
| Gross Weight / Net Weight | 110 kg / 85 kg |
| Door Type | Hand wheel-type quick-open |
| Door Safety | Door safety lock system |
| Seal Type | Self-inflating type seal |
| Display | Digital display with touch-key controls |
| Included Accessories | Two stainless steel sterilization baskets |
| Optional Accessory | Drying system |
Standard Accessories
- Two stainless steel sterilization baskets
- Power cable
- Operator’s manual
Ideal Applications
- Hospitals & Surgical Centers
- Dental Clinics & Oral Surgery
- Central Sterile Services Departments (CSSD)
- Medical & Research Laboratories
- Veterinary Clinics
- Beauty & Tattoo Studios
- Pharmaceutical Settings
Why Choose the TRS-100L(AUTO)?
The TRS-100L(AUTO) Automatic Horizontal Steam Sterilizer is engineered for busy clinical and laboratory environments that demand reliable, fully automatic sterilization with minimal operator intervention. The digital display and touch-key controls make cycle programming simple and intuitive, while the hand wheel-type quick-open door provides convenient access to the 100-liter chamber.
Safety is a top priority. The combination of door safety lock, over temperature and over pressure protection, and water lack protection ensures safe operation while protecting both personnel and valuable instruments. The self-inflating seal maintains optimal chamber conditions throughout the sterilization cycle.
With fully automatic operation—including auto cool air discharge, auto steam discharge, and auto shut-off with beep reminder—the TRS-100L(AUTO) simplifies the sterilization process, allowing healthcare professionals to focus on patient care rather than equipment operation.
For facilities requiring drying capability, the optional drying system can be added to expand processing capabilities to include fabrics and moisture-sensitive materials.
0
People watching this product now!
Description
Fully Automatic Steam Sterilization with Precision and Safety
The TRS-100L(AUTO) Automatic Horizontal Steam Sterilizer is a high-performance, fully automatic autoclave designed for reliable and efficient sterilization in hospitals, dental clinics, surgical centers, and laboratories. Featuring a 100-liter stainless steel chamber, digital display with touch-key controls, and a hand wheel-type quick-open door, this sterilizer combines user-friendly operation with robust construction for long-term reliability.
With fully automatic sterilization cycles, comprehensive safety protections, and the option to add a drying system, the TRS-100L(AUTO) delivers consistent sterilization results while ensuring operator safety and instrument protection.
Key Features
Fully Stainless-Steel Structure
The TRS-100L(AUTO) is constructed entirely from high-quality stainless steel, providing exceptional corrosion resistance, durability, and ease of cleaning. This ensures long-term reliable performance in demanding clinical and laboratory environments.
Hand Wheel-Type Quick-Open Door
The hand wheel-type quick-open door mechanism allows for fast, convenient access to the chamber while maintaining a secure seal during operation. The intuitive design simplifies loading and unloading of sterilized materials.
Door Safety Lock System
A built-in door safety lock system prevents the door from being opened while the chamber is under pressure, ensuring operator safety and preventing accidents.
Digital Display with Touch-Key Controls
The digital display provides clear, real-time information on working status, temperature, pressure, and cycle progress. Touch-key controls make it easy to set parameters and initiate cycles with minimal training.
Fully Automatic Operation
The TRS-100L(AUTO) features fully automatic sterilization cycles:
- Auto cool air discharge: Automatically removes cool air from the chamber to ensure effective steam penetration
- Auto steam discharge: Automatically releases steam after sterilization completion
- Auto shut-off with beep reminder: Cycle completion is signaled by an audible alert
Comprehensive Safety Protection
Multiple safety features ensure reliable and safe operation:
- Over Temperature & Over Pressure Auto-Protection: Automatically interrupts operation if safe limits are exceeded
- Water Lack Protection: Prevents operation when water levels are insufficient, protecting the unit from damage
- Door Safety Lock: Prevents door opening under pressure
Self-Inflating Type Seal
The self-inflating seal ensures a tight, reliable closure during sterilization cycles, maintaining optimal pressure and temperature conditions throughout the process.
Two Stainless Steel Sterilization Baskets
Includes two stainless steel sterilization baskets for organized loading and efficient processing of instruments, dressings, and other items.
Optional Drying System
The unit can be equipped with an optional drying system upon request, expanding processing capabilities to include moisture-sensitive materials such as fabrics and dressings.
