Triup High Frequency Mobile X-Ray (HM-200MD)

Product Description:

HM-200MD Mobile X-Ray Machine: Powerful, Portable, and Digital
Designed for critical care environments where patient mobility is limited, the HM-200MD is a high-frequency mobile medical diagnostic X-ray machine that brings advanced digital imaging directly to the bedside. Whether in emergency rooms, operating theaters, intensive care units, or isolation wards, this rugged and reliable system delivers exceptional image quality with the convenience of a wireless flat panel detector. It also serves as an ideal standby solution for conventional X-ray departments, ensuring you are always prepared for any situation.

Superior Imaging Performance in a Mobile Package
The HM-200MD is engineered to provide consistent, high-quality radiography wherever it is needed most.

• Powerful High-Frequency Generator: The 20kW high-frequency high-voltage generator ensures stable and efficient X-ray output. With a maximum tube voltage of 125kV and a maximum tube current of 320mA, it is capable of penetrating a wide range of anatomical densities.
• High-Quality X-Ray Tube: Featuring a rotating anode Chinese X-ray tube with a dual focus (1.0mm/2.0mm) and an anode heat capacity of 140KHU, the system is built for sustained performance during demanding procedures.
• Digital Readiness (HM-200MD Model): This model is specifically configured to operate with an optional 17″ x 17″ Flat Panel Detector available in both wired and wireless configurations. This allows for immediate transition to digital radiography (DR), eliminating film costs and accelerating workflow.

Designed for Demanding Clinical Environments
Mobility and ease of use are at the core of the HM-200MD’s design, enabling rapid response in critical situations.

• Effortless Maneuverability: The mechanical design allows for precise positioning. The height from the X-ray tube focus to the ground reaches up to 1888mm, and the tube arm can rotate from left 90° to right 90°, providing excellent coverage for bedridden patients.
• Intuitive Operation Panel: The system features a 19-inch touch screen all-in-one computer (exclusive to the HM-200MD model) that serves as the central workstation. This user-friendly interface simplifies exam setup and image review.
• 48 Automatic Program Radiography (APR): With 48 preset anatomical programs, the system simplifies operation by automatically setting optimal exposure parameters, reducing technologist error and speeding up exam times.
• Standard Power Supply: The unit operates efficiently on a standard 220V±10% power supply, making it incredibly convenient to use in various locations without the need for specialized electrical infrastructure.

Precision and Safety Features

• High-Precision Controls: The microprocessor-controlled system ensures high precision in exposure time and tube current control for consistent, repeatable results.
• Advanced Collimator: The manual multi-leaf collimator features high brightness (>160Lux) and can cover a maximum field of 17″ x 17″ at 100cm SID, ensuring precise beam limitation and patient safety.
• Overload Protection: An integrated overload protection system safeguards the X-ray tube and generator, extending the life of the equipment and preventing operational errors.
